FISHFINDERS 20

SERIES OF CHARTPLOTTERS
WITH ECHOMAP™ UHD TRANSDUCER
ECHOMAP UHD chartplotters fitted with 6”, 7” and 9”
screens have preloaded basic map of the wold and are
compatible with BlueChart g3 g3 Vision & Navionics nav
maps; they also use Quickdraw Contours map creation tool.
Multifunctional ECHOMAP UHD sv devices are available in
versions with 7” and 9” touchscreens and they are equipped
with an interface with buttons. They are fitted with wide angle
CHIRP transducer and Ultra High Definition ClearVü i SideVü
scanning sonars. ECHOMAP UHD on the other hand have
6” and 7” screens, additional set of buttons and a transducer
that supports the Ultra High Definition ClearVü scanning
sonar. All models with 7” and 9” screens are compatible with
Panoptix LiveScope™ system. They also have a built-in Wi-Fi 010-02329-01
module and the ActiveCaptain app that provides direct link
®
to the OneChart™ platform allowing to purchase news maps,
to update the software and to push notifications, containing
data gathered by the Garmin QuickDraw™ community and
much more. Devices were fitted with a quick connector
for mounting convenience and they are compatible with
NMEA 2000 and NMEA 0183 networks. On top of that
®
multifunctional ECHOMAP UHD devices with 7” and 9”
screens can be used with a Force™ trolling engine, allowing to
control the engine directly form the chartplotter screen. It is
also possible to create tracks based on selected waypoints and
to track the trace.

010-02337-01

INCH
Garmin ploter ECHOMAP 62cv UHD 010-02329-01 6
Garmin ploter ECHOMAP 72cv UHD 010-02337-01 7
Garmin ploter ECHOMAP 92sv UHD 010-02341-01 9
SU-1

010-02341-01

MAIN FEATURES:

• Bright, sunlight-readable 6”, 7” or 9” screen; multifunctional device with a 7” and 9” touchscreen;
• 7” and 9” screen models work with the Panoptix sonar and the Panoptix LiveScope system;
• Compatible with Ultra High Definition ClearVü and Ultra High Definition SideVü scanning sonars and with the traditional Garmin CHIRP
sonar; SideVü option available only in models with 7” and 9” screens (sv);
• 7” and 9” models can share data with other devices such as ECHOMAP™ Plus, ECHOMAP UHD and ECHOMAP Ultra. Sonar data,
waypoints, tracks and additional maps can be shared;
• Devices are compatible with NMEA 2000 and NMEA 0183, enabling autopilot, SteadyCast™ track sensor, FUSION Link™ audio system
®
and engine data display;
• All versions of the device have basic map of the world preloaded and are compatible with a BlueChart g3 and g3 Vision with an
AutoGuidance function;
• 7” and 9” models are compatible with a Force™ engine allowing to control it from the device, and to create tracks based on waypoints,
follow the pre-selected trace and much more.
