20         FISHFINDERS



             PANOPTIX LIVESCOPE™ SCANNING FISHFINDER SYSTEM
             It is completely clear to us that it is by far the most advanced fishfinder technology created and that it will change fishing forever. Panoptix LiveScope™
             is a real-live scanning fishfinder that displays comprehensible representation of the underwater terrain and moving objects. It is so precise that you will not
             only be able to see all the fish there are, but even your own lure being hauled. You don’t even need to move the boat; the projection is so detailed you will be
             able to distinguish different species!












                                                                          Panoptix LiveScope™      Panoptix LiveScope™
                                                                         with a frontward beam     with a downward beam

                                                                   Two different modes of work in one converter - you get both modes: the
                                                                   LiveScope™ downward beam and the LiveScope™ frontward beam in one
                                                                   converter. Thanks to that you will easily adjust the right setting for the used
                                                                   angling technique. In order to receive a clear picture of the underwater
                                                                   scenery around the boat, use the LiveScope™ frontward beam mode.  If you
                                                                   prefer to check what is going on underneath the boat, apply the LiveScope™
                     SYSTEM PANOPTIX LIVESCOPE  010-01864-00       downward beam mode. Selected mode will automatically be updated on the
                                                                   display, while picture stabilization system AHRS will pass the test even in the
                                           SU-1                    toughest conditions.





               In order to use the Panoptix LiveScope™ you will need
             a proper Garmin chartplotter
             (i.e. GPS MAP 8410 XSV, 8412 XSV, 8416 XSV,
             ECHOMAP ULTRA 102SV or 122SV, ECHOMAP 92sv
             Plus or ECHOMAP 72sv Plus).










             PANOPTIX LIVESCOPE™ LVS12 TRANSDUCER
             The 12-pin Panoptix LiveScope LVS12 transducer provides an economical option for adding real-time scanning sonar to your GPSMAP  8400xsv series
                                                                                                   ®
             chartplotter/sonar combo without needing a black box system. The transducer includes trolling motor mount and transom mount.


                                           MAIN FEATURES:


                                          •  provides 30-degree forward and 30-degree down real-time
                                            scanning sonar views;
                                          •  forward view shows structure and fish swimming in real time
                                            up to 60 m (200 ft) away from your boat; down view shows
                                            structure and fish swimming in real time up to 60 m deep
                                            below your boat;
                                          •  both forward and down views included in one transducer,
                                            with no manual transducer adjustment needed;
                                          •  does not require a black box, making installation easy;
                                          •  includes Attitude Heading Reference System (AHRS)
                                            for a stable view in rough conditions.






                                           PANOPTIX LIVESCOPE LVS12  010-02143-00
                                                              SU-1
